Deploy massive compute anywhere with the
latest family of powerful, secure servers engineered to accelerate
automation and innovation.
Your innovation engine
The Dell PowerEdge R760xs is thoughtfully
crafted to fit in your current infrastructure and deliver the right
performance features to support your demanding enterprise applications.
Just right
Strike the right balance between performance
and flexibility with this air-cooled solution designed for the most
popular IT applications.
Add up to two 5th Generation Intel® Xeon® Scalable processors with up to 28 cores per socket for faster performance
Accelerate in-memory workloads with up to 16 DDR5 RDIMMS up to 5200 MT/sec (max 1.5TB)
Improve data throughput and reduce latency with support up to 8 I/O devices
Up to available 6 PCIe slots, 1 OCP 3.0 networking slot, and 1 dedicated PERC slot
Storage options include up to 12 x 3.5” HDDs/SSDs; or up to 16 x 2.5” HDD/SSDs, plus up to 8 x NVMe drives
Acceleration with up to 2xSW HH/HL GPU (max 75W)
Next Gen HW SAS4 RAID (PERC12)
Hot-plug NVME BOSS-N1 (2xM.2) for boot
Chassis
Chassis
3.5" Chassis with up to 12 Hard Drives (SAS/SATA)
DELL 5 YEARS PRO SUPPORT
• Access on a 24x7 basis (including holidays)2 to the Dell Customer Service and Support organization for troubleshooting assistance of Supported Products.
• On-site dispatch of a technician and/or delivery of replacement parts to the installation site or other Customer business
• Replacement parts, when deemed necessary to resolve or prevent an issue.
• ProSupport entitlements include access to TechDirect and SupportAssist, which are enabled via connectivity software,
▪ Proactive issue detection and automated case creation
▪ Predictive detection of hardware failures and automated case creation
▪ Self-serve case creation
▪ Self-serve part dispatch
• Collaborative Assistance
• Comprehensive Software Support
MEMORY
32GB (2x 16GB RDIMM, 5600MT/s, Single Rank)
STORAGE FRONT:
1) 2.4TB Hard Drive SAS ISE 12Gbps 10K 512e 2.5in with 3.5in HYB CARR Hot-Plug
CHASSIS
Chassis with Up to 12 x 3.5 inch SAS/SATA Drives
Riser Config 0, No Riser, 3x16 + 1x8
High Performance Heatsink
Trusted Platform Module 2.0 V5
NETWORK.
Motherboard with Broadcom 5720 DP 1G
POWER
Dual, Fully Redundant(1+1), Hot-Plug Power Supply,1100W MM(100-240Vac) Titanium
Power Cord 250V (10 Ampere, 2 Feet)
PERC H755 Controller, Front
Low Profile PERC Card Bracket
Unconfigured RAID
Other Information
Standard Specs And Options
MEMORY OPTIONS
• 16 DDR5 DIMM slots, supports RDIMM 1.5 TB max, speeds up to 5200 MT/s, supports registered ECC DDR5 DIMMs only
STORAGE CONTROLLER OPTIONS
• Internal Controllers: PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i, HBA465i
• Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 1, 2 x M.2 NVMe SSDs or USB
• External HBA (non-RAID): HBA355e; Software RAID: S160
GPU OPTIONS
2 x 75 W SW, LP
DRIVE BAY OPTIONS
Front bays:
• 0 drive bay
• Up to 8 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB
• Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 288 TB
• Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.88 TB
• Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) max 121.6 TB
• Up to 16 x 2.5-inch (SAS/SATA) + 8 x 2.5-inch (NVMe)
(HDD/SSD) max 244.48 TB
Rear bays:
• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB
(supported only with 12 x 3.5-inch SAS/SATA HDD/SSD
configuration)
POWER OPTIONS
• 1800 W Titanium 200—240 VAC or 240 VDC
• 1400 W Titanium 100—240 VAC or 240 VDC
• 1400 W Platinum 100—240 VAC or 240 VDC
• 1400 W Titanium 277 VAC or HVDC (HVDC stands for HighVoltage DC, with 336V DC)
• 1100 W Titanium 100—240 VAC or 240 VDC
• 1100 W -(48V — 60V) DC
• 800 W Platinum 100—240 VAC or 240 VDC
• 700 W Titanium 200—240 VAC or 240 VDC
• 600 W Platinum 100—240 VAC or 240 VDC
DIMENSIONS & WEIGHT
• Height – 86.8 mm (3.41 inches)
• Width – 482 mm (18.97 inches)
• Depth – 707.78 mm (27.85 inches) – without bezel
721.62 mm (28.4 inches) – with bezel
• Weight – Max 28.6 kg (63.0 lbs.)
PORTS
Front Ports:
• 1 x iDRAC Direct (Micro-AB USB) port, 1 x USB 2.0, 1 x VGA
Internal Ports: 1 x USB 3.0 (optional)
Rear Ports
• 1 x Dedicated iDRAC Ethernet port, 1 x USB 2.0, 1 x USB 3.0,
1 x VGA, 1 x Serial (optional)
PCIe SLOTS
PCIe
• 1 CPU Configuration: Up to 4 PCIe slots (2 x8 Gen5, 1 x16 Gen4, 1 x8 Gen4)
• 2 CPU configuration: Up to 6 PCIe slots (2 x16 Gen5, 3 x16 Gen4, 1 x8 Gen4)
O/S OPTIONS SUPPORTED
• Microsoft Windows Server with Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
• VMware ESXi
• Canonical Ubuntu Server LTS
For specifications and interoperability details, see Dell.com/OSsupport.
