| Chassis | |
| Chassis | CHASSIS WITH 8 x 2.5" BACKPLANE DELL 5 YRS ON SITE WARRANTY 1) Intel Xeon Silver 4310 (12Cores,24 Threads(HT), 3.3GHz,18MB Cache,120W) MEMORY 32 GB ( 2 x 16GB RDIMM, 3200MT/s, Dual Rank) STORAGE - FRONT ARRAY 1) 480GB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug AG Drive, 2) 480GB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug AG Drive, Riser Config 0, No PCIe Riser, 1 CPU Power Saving BIOS Setting Motherboard Planner with Onboard LOM SAS/SATA Drives Capable Front PERC Mechanical Parts, rear load Chassis with up to 8 x 2.5inch HD 700 Watt HLAC Dual Hot-Plug Titanium PS (1+1) PERC H755 Controller Front |
| Other Information | |
| Included | DELL 5 YEARS NEXT BUSINESS DAY ON SITE BASIC WARRANTY |
| Standard Specs And Options | MEMORY • 16 DDR4 DIMM slots, supports RDIMM 1 TB max, speeds up to 3200 MT/s • Supports registered ECC DDR4 DIMMs only STORAGE CONTROLLERS• I nternal controllers: HBA345, PERC H345, PERC H355, PERC H745, PERC H755, S150, H755N, HBA355i • Internal Boot: Internal Dual SD Module, Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2 x M.2 SSDs, USB • External PERC (RAID): PERC H840 • External HBAs (non-RAID): HBA355e DRIVE BAYS Front bays: • Up to 8 x 2.5-inch SAS/SATA (HDD) max 120 TB • Up to 16 x 2.5-inch SAS/SATA (HDD) max 240 TB • Up to 24 x 2.5-inch SAS/SATA (HDD) max 360 TB • Up to 8 x 3.5-inch SAS/SATA (HDD/SAS) max 120 TB • Up to 8 x 3.5-inch SAS/SATA (HDD) + 8 x 2.5-inch NVMe (SSD) max 240 TB POWER SUPPLIES 600 W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant • 700 W Titanium Mixed Mode (200-240Vac or 240Vdc) hot swap redundant • 800 W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant • 1100 W -48Vdc hot swap redundant (CAUTION: only works with -48Vdc to -60Vdc power input) • 1100 W Titanium Mixed Mode (100-240Vac or 240Vdc) hot swap redundant • 1400 W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant • 1800 W Titanium Mixed Mode (200-240Vac or 240Vdc) hot swap redundant • 2400 W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant DIMENSIONS • Height – 459.0 mm (18.07 inches) • Width – 200.0 mm (7.87 inches) • Depth – 663.5 mm (26.12 inches) – without bezel 680.5 mm (26.79 inches) – with bezel EMBEDDED MANAGEMENT DRAC9 • iDRAC Direct • iDRAC Service Module • iDRAC RESTful with Redfish • Quick Sync 2 wireless module OPEN MANAGE SOFTWARE OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage SupportAssist plugin • OpenManage Update Manager plugin EMBEDDED NIC 2 x 1 GbE LOM PORTS: Front Ports • 1 x iDRAC Direct (Micro-AB USB) port (optional) • 1 x USB 2.0 • 1 x USB 3.0 Rear Ports • 1 x USB 2.0 • 1 x iDRAC Direct (Micro-AB USB) port • 1 x Serial (optional) • 1 x USB 3.0 • 2 x Ethernet OS SUPPORTED Canonical Ubuntu Server LTS • Citrix Hypervisor • Microsoft Windows Server with Hyper-V • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi For specifications and interoperability details, see Dell.com/OSsupport. |
- Brand: Dell
Tag Number: 22AO CM2KZ64
Stock ID: 10431
Availability: In Stock
-
£3,717.60£5,288.40
- £3,098.00 Ex VAT @ 20%
